主要外形及连接尺寸
MPa |
DN |
L |
D1 |
D2 |
H |
n-M |
MPa |
DN |
L |
D1 |
D2 |
H |
n-M |
0.6 |
50 |
43 |
90 |
110 |
325 |
4-M12 |
1.0 |
50 |
50 |
100 |
125 |
325 |
4-M16 |
65 |
46 |
110 |
130 |
340 |
4-M12 |
65 |
50 |
120 |
145 |
340 |
4-M16 |
||
80 |
46 |
125 |
150 |
355 |
4-M16 |
80 |
50 |
135 |
160 |
355 |
4-M16 |
||
100 |
52 |
145 |
170 |
405 |
8-M16 |
100 |
50 |
155 |
180 |
405 |
8-M16 |
||
125 |
56 |
175 |
200 |
440 |
8-M16 |
125 |
50 |
185 |
210 |
440 |
8-M16 |
||
150 |
56 |
200 |
225 |
520 |
8-M16 |
150 |
60 |
210 |
240 |
520 |
8-M20 |
||
200 |
60 |
255 |
280 |
580 |
8-M16 |
200 |
60 |
265 |
295 |
580 |
8-M20 |
||
250 |
68 |
310 |
335 |
670 |
12-M16 |
250 |
70 |
320 |
350 |
670 |
12-M20 |
||
300 |
78 |
362 |
395 |
820 |
12-M20 |
300 |
80 |
368 |
400 |
820 |
12-M20 |
||
350 |
78 |
412 |
445 |
925 |
12-M20 |
350 |
90 |
428 |
460 |
925 |
16-M20 |
||
400 |
102 |
462 |
495 |
1030 |
16-M20 |
400 |
100 |
482 |
515 |
1030 |
16-M22 |
||
450 |
114 |
518 |
550 |
1180 |
16-M20 |
450 |
120 |
532 |
565 |
1180 |
20-M22 |
||
500 |
127 |
568 |
600 |
1290 |
16-M20 |
500 |
130 |
585 |
620 |
1290 |
20-M22 |
>>>>>>>>>>
